Steel Lead Lined Door

Door Type	Steel Lead Lined Door
Criteria	Nuclear/Radiation Protected
Rating	Not Applicable
Door Thickness	44mm
Standards	AERB/DRS
Application	Radiology & Nuclear Medicine

Construction Details

• Steel Frame Profile Design-BPFPL 100x50

• Frame Manufactured with 1.2mm Galvanized Steel

• Shutter Thickness – 44mm

• Shutter Infill – Honeycomb/Mineral wool including 2mm Lead Sheet

• Shutter Manufactured with 1mm Galvanised Steel

• Ingle Glazed Lead Glass as per requirement of size 200mmX300mm (5mm+ - 2mm)

Optional Hardware

• Mortise Dead Lock Set with Cylinder- complete with D Shape Pull handle for Push / Pull Operations

• Mortise Sash Lock with Cylinder – Complete with Lever Handle for Push / Pull Operations

Recommended Hardware

• SS Ball Bearing Hinges – SS 304 of Size 100mm x 75mm x 3mm

• Door Closer – Fire rated

• Tower Bolt / Flush Bolt

Recommended Finishes

• Power Coating in desired RAL Shade Code

• Polyurethane Coating in desired RAL Shade Code

• Selective Wood Grain Finishes available
